The UNI-T UT3208+ is a precision 8-channel temperature recorder / tester optimized for multi-point temperature monitoring in industrial, laboratory, and manufacturing environments. With support for eight thermocouple inputs, fast scanning, and a full-color 4.3″ display, it offers a versatile and reliable solution for collecting and analyzing temperature data across multiple points simultaneously.
Whether you’re testing electrical components, ovens, motors, or environmental chambers, the UT3208+ delivers real-time multi-channel readings, graphical display, and data export options—making it ideal for quality assurance, R&D, and production lines.
FEATURES:
- 8 Input Channels — Monitor eight independent thermocouple sensors at once.
- Wide Temperature Range — −200 °C to 1800 °C, depending on thermocouple type.
- High Resolution — 0.01 °C resolution for precise readings.
- Fast Scanning / Sampling — Up to 100 ms per channel (i.e. 10 readings/sec) in fast mode.
- Multiple Display Modes — Numeric, curve graph, histogram views.
- Alarm / Comparator Function — Upper and lower limit thresholds per channel, color and sound alerts.
- Data Storage & Export — Built-in 8 GB USB support, saving data in CSV format.
- Communication Interfaces — RS-232, LAN (Ethernet), USB Device.
- Cold-Junction Compensation — Automatic compensation for sensor junctions.
- Open-Circuit Detection — Auto detect disconnected or broken thermocouple leads.
- User-Friendly UI — 4.3″ true-color TFT LCD interface.
INCLUDES:
1 x UT3208+ multi-channel temperature tester
SPECIFICATIONS:
| Parameter | Specification |
|---|---|
| Model | UNI-T UT3208+ |
| Channels | 8 channels (expandable in UT3200+ series to 16, 24, etc.) |
| Thermocouple Types Supported | J, K, T, E, S, N, B, R |
| Temperature Range | –200 °C to 1800 °C (varies by thermocouple type) |
| Resolution | 0.01 °C |
| Scanning / Sampling Speed | Up to 100 ms (fast mode) / two scanning rates supported |
| Display | 4.3″ TFT LCD (true color) |
| Data Storage | 8 GB USB (save data, screenshots, configuration) |
| Alarm / Comparator | Upper/lower limit setting per channel, audio + visual alert |
| Communication Interfaces | RS-232, LAN, USB Device |
| Cold Junction Compensation | Yes |
| Open-Circuit Detection | Yes |
| Power Supply | AC 100–240 V, 50/60 Hz (max ~10 VA) |
| Environmental Conditions | Operating: 10 °C to 40 °C, humidity ≤ 80 % RH (non-condensing) |
| Dimensions | 214 mm × 89 mm × 340 mm (approx.) |
| Weight | ~3.4 kg (net) |
