UTi256G is a professional enhanced thermal camera specially designed for industrial use with high IR resolution 256×192 and wide temperature range:-20℃~550℃. The professional manual focus lens can flexibly adjust the focal length according to different objective distances and provide high-quality images. The 3.5’’ large IPS touch screen take more efficient and convenient operation experience for users. UTi256G also supports various outstanding functions: such as Wi-Fi, voice recording, laser pointer, on-screen analyzer， etc. They are perfect troubleshooting tools for many industrial applications.
APPLICATIONS:
- Solar panel inspection, electric power tower inspection, electricity facilities inspection, automotive maintenance， mechanical equipment inspection, heating equipment inspection, building&HVAC inspection and other wide range applications: petrochemical, metallurgy, industry etc.
FEATURES:
- 3.5″ IPS touchscreen (640×480)
- IR resolution:256×192
- Temperature measurement range: -20℃to 550℃
- On-screen analyzer :3 Points/3 Lines/3 Rectangles/3 Circles
- Digital camera resolution: 5MP
- Focus: Manual focus
- Digital zoom: 2x, 4x
- Wi-Fi and Bluetooth connection through Mobile App
- PC software: analysis and real-time image projection
- Voice recording
- Image modes: Thermal, Visual image, Fusion,PIP
- Color palettes: 7(White hot, Black hot, Red hot, Ironbow, HC Rainbow, Rainbow, Lava)
- Isotherm: 5(Auto/Manual/Above/Below/Section)
- 5200mAh replaceable battery pack (Type-C rechargeable)
- IP54
- 2m drop proof.
INCLUDES:
1 x UTi256G, 1 x Micro SD card, 1 x Type-C USB cable, 1 x Wrist strap, 2 x Li-ion battery, Documents download operation guide card, English manual and 12-month warranty
SPECIFICATIONS:
| Technical Data | |
| IR resolution (Pixels) | 256×192 |
| Display | 3.5‘’ Touch (640×480) |
| Field of view(FOV) | 28°×20° |
| Thermal sensitivity(NETD) | ≤40mK |
| Spatial resolution(IFOV) | 1.91mrad |
| Frame rate | ≤30Hz |
| Spectral range | 7.5~14µm |
| Focus | Manual |
| Temperature measurement range | -20℃~550℃ |
| Accuracy | ±2℃ or ±2% whichever is greater |
| Emissivity | 0.01~1.00 adjustable (0.95 default) |
| Functions | |
| Colour palettes | 7 (White hot, Black hot, Red hot, Ironbow, Rainbow HC, Rainbow, Lava) |
| Image modes | Thermal, Visual image, Fusion, PIP |
| On-screen analyzer | 3 Points/3 Lines/3 Rectangles/3 Circles |
| Digital camera resolution | 5MP |
| Digital zoom | 2x, 4x |
| Hi/Lo temperature alarm | Icon |
| Isotherm | Auto/Manual/Above/Below/Section |
| Software analysis | PC+APP |
| Voice recording | √ |
| Wi-Fi / Bluetooth | √/√ |
| Laser pointer | √ |
| General Characteristics | |
| Battery | Detachable Li-ion battery pack(3.7V 5200mAh) |
| Battery operation time | About 5 hours (with Wi-Fi off) |
| USB | Type-C |
| IP rating | IP54 |
| Drop-proof | 2m |
| Storage | 8GB Internal 32GB External |
| Image storage format | JPEG |
| Certificates | CE,UKCA,FCC,RoHS |
| Product net weight | 880g |
| Product size | 261mm×104mm×97mm |
| Packing Details | |
| Standard accessories | Micro SD card, Type-C USB cable, Wrist strap, English manual, Li-ion battery pack×2, Documents download operation guide card |
| Standard individual packing | Toolbox,box |
